High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40

Minimum Order Quantity : 1 Price : USD2750 - USD2900
Packaging Details : 1PC/BOX Delivery Time : 30 Working Days
Payment Terms : T/T Supply Ability : 20PCS Per Month
Place of Origin: CHINA Brand Name: JINSP
Certification: CE ISO9001 IP30 IP40 Model Number: BA1023

Detail Information
Wavelength Range: 280nm-1100nm Dimension: 78 *45 *38.5mm (without Base)
Power Supply: USB Powered Or 12V DC Externally Powered Effective Sensing Area: 11mm*7mm
Sensor: 2.3MP, 1/1.2" CMOS SNR: 40 DB
Cell Size: 5.86μm*5.86μm Minimum Detection Area: 30μm (5 Pixls)
Maximum Frame Rate: 41 Fps@1920*1200 Data Interface: USB3 Vision, GenlCam
Highlight:

High Resolution Laser Beam Profiler

,

High Resolution Beam Profiling Camera

,

30μM Laser Beam Profiler

Product Description

High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40
Product Specifications
Wavelength Range: 280nm-1100nm
Dimension: 78 *45 *38.5mm (without base)
Power supply: USB powered or 12V DC externally powered
Effective sensing area: 11mm*7mm
Sensor: 2.3MP, 1/1.2" CMOS
SNR: 40 dB
Cell size: 5.86μm*5.86μm
Minimum detection area: 30μm (5 pixls)
Maximum frame rate: 41 fps@1920*1200
Data interface: USB3 Vision, GenlCam
280nm ~1100nm CMOS USB Laser Beam Profiler

This high-resolution laser beam profiler offers precise measurement and analysis capabilities for a wide range of optical applications.

Product Variants
Product Code BA1023 BA1024Ga BA1024Gb BA1024Ua BA1024Ub
Probe wavelength range 280nm ~ 1100nm
Effective sensing area 11mm*7mm 13mm*8.7mm 7mm*5.5mm 4.9mm*3.7mm
Sensor 2.3MP, 1/1.2" CMOS 20MP, 1" CMOS 2MP, 1/1.7" CMOS 0.4MP, 1/2.9" CMOS
SNR 40 dB 44.9 dB 41.5 dB 43.7 dB 42.9 dB
Gain control 0~20dB 0~24dB
Primary Applications
  • Measuring the size of the light spot
  • Marking the position of the light spot
  • Comparing changes in the light spot
  • Real-time monitoring of laser beams
Software Features
  • Compatible with Windows 10 (64-bit) and Linux (Ubuntu X86)
  • Comprehensive camera control including exposure, gain, and resolution adjustments
  • Real-time pseudo-color visualization for 2D and 3D spot representations
  • Measurement of spot axes length/width, ellipticity, and rotation angle
  • Special functions including dual light spot comparison and background cropping
  • Data recording and export capabilities for all measured parameters
High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 0
Software Visualization Examples
High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 1 High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 2 High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 3 High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 4 High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 5
Industry Applications
  • Beam quality measurement for laser systems
  • Optical research and laser detection studies
  • Real-time monitoring in laser processing
  • Light intensity distribution monitoring
  • Specialized applications in instrument manufacturing
High Resolution 30μM Laser Beam Profiler Beam Profiling Camera IP30 IP40 6
Frequently Asked Questions
Q1: This is the first time I use it, is it easy to operate?
A1: We provide an English manual and guide video, along with professional technical support from our engineers.
Q2: Can you offer an operation training?
A2: We offer both on-site training at our facility and can send engineers to your location for installation, training, and debugging.
Q3: How to receive the best price in the shortest time?
A3: Please provide detailed specifications with your inquiry for a prompt, accurate quotation.
Q4: If the spectrometer has a problem in my place, what could I do?
A4: The product comes with a one-year warranty. Our technicians will diagnose and repair any issues at no cost during this period.
Q5: What about quality assurance?
A5: All products undergo rigorous quality inspection before shipment, with documentation available upon request.
