High Precision Fiber Optic Spectrometer With Customizable Spectral Resolution

Contact Now

High Precision Fiber Optic Spectrometer With Customizable Spectral Resolution

Minimum Order Quantity :	1	Price :	USD3900 - USD4300
Packaging Details :	International Shipping Package	Delivery Time :	30-400 working days
Payment Terms :	T/T, Western Union	Supply Ability :	100PCS/30-40 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	ISO9001 CE	Model Number:	SR100B

Detail Information
Spectrual Range:	200nm - 1100nm	Effective Pixels:	2048*64
Pixel Size:	28.672*0.896mm	Integration Time:	4ms~900s
Dimensions:	180mm120mm50mm	Weight:	1.2kg
Highlight:	High Precision Fiber Optic Spectrometer , High Precision Back Illuminated Fiber Spectrometer , Customizable Fiber Optic Spectrometer

Product Description

High Precision Fiber Optic Spectrometer With Customizable Spectral Resolution

Key Specifications

Attribute	Value
Spectral Range	200nm - 1100nm
Effective pixels	2048*64
Pixel Size	28.672*0.896mm
Integration Time	4ms~900s
Dimensions	180mm120mm50mm
Weight	1.2kg

Product Overview

The SR100B spectrometer represents a pinnacle of technological achievement in high-performance, back-illuminated CCD sensor devices. Featuring the renowned Hamamatsu S10420 CCD chip with a large sensing area, this instrument delivers stable, accurate spectral readings for industrial, laboratory, and research applications.

Technical Parameters

Category	Parameter	Value
Detector	Chip Type	Back-illuminated cooling Hamamatsu S10420
	Effective Pixel	2048*64
	Pixel Size	14*14μm
	Sensing Area	28.672*0.896mm
Optical Parameters	Optical Design	F/4 cross type
	Numerical Aperture	0.13
	Focal Length	100mm
	Entrance Slit Width	10μm,25μm,50μm,100μm,200μm (customizable)
	Fiber Interface	SMA905, free space
Electrical Parameters	Integration Time	4ms~900s
	Data Output Interface	USB3.0, RS232, RS485, 20pin connector
	ADC Bit Depth	16-bit
	Power Supply	5V
	Operating Current	<3.5A

Available Models

Model	Spectral Range(nm)	Resolution(nm)	Slit(μm)
SR100B-G21	200~1100	2.2 (50μm) 1.5 (25μm) 1.0 (10μm)	50 25 10
SR100B-G24	200~875 350~1025	1.6 (50μm) 1.0 (25μm) 0.7 (10μm)	50 25 10
SR100B-G28	200~345	0.35 (50μm) 0.2 (25μm) 0.14 (10μm)	50 25 10

Note: Certain models are primarily designed for Raman applications.

Key Features

High sensitivity with back-illuminated detector and optimized ultraviolet band
High resolution (<1.0nm@10μm for 200~1100nm range)
Broad spectral range (180~1100nm) with multiple interface compatibility
Excellent signal-to-noise ratio and thermal stability

Applications

Absorption, transmittance and reflection spectrum detection
Light source and laser wavelength characterization
OEM modules for fluorescence and Raman spectroscopy

About JINSP

JINSP Company Limited is a professional supplier with over 17 years of experience in spectral detection technology products, including Raman, FT-IR, and LIBS technologies. With over 200 patent applications, our core technologies have reached internationally leading levels.

Headquartered in Beijing with a manufacturing facility in Jiangsu, China, JINSP holds ISO9001:2015, ISO14001:2015, and ISO45001:2018 certifications. We can provide various required certifications including CE, ECAC, and security testing reports.

Frequently Asked Questions

Q1: This is my first time using this product. Is it easy to operate?

A1: We provide an English manual and instructional video, along with professional technical support meetings with our technicians.

Q2: Do you offer operation training?

A2: Your technicians can receive training at our factory, or our engineers can provide on-site support including installation, training, debugging, and maintenance.

Q3: What's your website?

A3: Visit us at www.jinsptech.com

Q4: What about your quality assurance?

A4: All goods undergo thorough quality inspection before shipment, with inspection photos available upon request.
