The VPH grating allows for high diffraction efficiency and zero-aberration, resulting in superior performance and accuracy. The spectrometer also supports multiple channels, allowing for simultaneous measurements of different samples.
The Transmission Fiber Spectrometer is highly stable, ensuring reliable and consistent performance. It is equipped with a USB 2.0 interface for easy connectivity and data transfer.
This product falls under the category of fiber optic spectrometers and is ideal for use in a wide range of applications, including chemistry, biology, and material science.
Product Parameters:
|
|
Performance Indicators
|
Parameters
|
|
Detector
|
-
|
See product model table
|
|
Optical
Parameters
|
Wavelength Range(ST100S1)
|
785nm~988nm
corresponds to 0~2600cm-1
|
|
Optical Resolution(ST100S1)
|
0.35nm, corresponds to 5cm-1(50μm slit)
0.25nm, corresponds to 3cm-1(25μm slit)
|
|
Grating Type
|
VPH volume holographic transmission grating
|
|
Diffraction Efficiency
|
>85%
|
|
Fiber Interface
|
SMA905, FC, Φ10mm multi-core optical fiber
|
|
Number of Channels
|
6 channels (for multi-core optical fiber with
core diameter of 200μm)
|
|
Numerical Aperture
|
0.25
|
|
Electrical
parameters
|
Integration Time
|
1ms-3600s
|
|
Data Output Interface
|
USB2.0
|
|
ADC Bit Depth
|
16-bit
|
|
Power Supply
|
DC12V
|
|
Operating Current
|
3A (typical value 2A)
|
|
Operating Temperature
|
-20°C ~60°C
|
|
Storage Temperature
|
-30°C ~70°C
|
|
Operating Humidity
|
<90%RH (no condensation)
|
|
Physical
Parameters
|
Dimensions
|
354 . 9mm*1 98 . 7mm*1 23 . 5mm
|
|
Weight
|
<6Kg (including camera)
|
List of product model table:
|
Product model
|
ST100S1
|
ST100S3
|
ST100S4
|
|
Detector Brand &
Model
|
AndoriVac 316
|
Raptor261FI
|
Raptor261BI
|
|
Chip Type
|
Deep depletion of
back illumination
|
Front
illumination
|
Deep depletion
of back
illumination
|
|
Quantum
Efficiency
|
82%@900nm
|
38%@900nm
|
80%@900nm
|
|
Number of Pixels
|
2000*256
|
2048*256
|
2048*256
|
|
Pixel Size /μm
|
15*15
|
15*15
|
15*15
|
|
Image Area/mm
|
30*3.8
|
30*3.8
|
30*3.8
|
|
Cooling
Temperature /℃
|
-70
|
-70
|
-70
|
|
* Customization available for other ranges
|
Technical Characteristics:
- High Diffraction Efficiency: VPH grating, diffraction efficiency up to 90%
- Support multiple channels: Compatible with SMA905 fiber, FC connector, and Φ10mm multi-core fiber interfac
- High Flux: numerical aperture is 0.25
- Highly stable: No adjustable components, applicable to labs and industries
Applications:
The JINSP ST100S High-Throughput Transmission Fiber Spectrometer is a top-of-the-line product for various applications. Its deep-cooling CCD detector type and 6-channel capability make it perfect for 785nm confocal Raman microscopy. The VPH volume holographic transmission grating ensures accurate and precise results, making it ideal for transmission Raman spectroscopy.
For the best price, please provide us with details such as wavelength, detector, effective pixels, and focal length. We will send you a quotation with details to your email in the shortest time possible.
Packing:
Company Introduction:
Company Profile and Certification: JINSP Company Limited originates from Tsinghua University and has 17 years of experience in developing spectroscopic technology. As a leading supplier of spectroscopic technology, JINSP Technology offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security, customs, and fiber optic spectrometers. Our products are available nationwide and are exported to over 30 countries, with cumulative sales exceeding 3,000 units.
FAQ:
Q: What is the brand name of the product?
A: The brand name of the product is JINSP.
Q: What is the model number of the product?
A: The model number of the product is ST100S.
Q: What is the delivery time for the product?
A: The delivery time for the product is 40-70 working days.
Q: What are the payment terms for the product?
A: The payment terms for the product are T/T and Western Union.
Q: What is the supply ability for the product?
A: The supply ability for the product is 50 PCS/70-90 days.
Q: Is the price for the product negotiable?
A: Yes, the price for the product is negotiable.
Q: What is the place of origin for the product?
A: The place of origin for the product is China.
Q: What are the packaging details for the product?
A: The packaging details for the product are customized packaging.
