Rapid and Non-Destructive Testing JINSP SR100N25 Micro Near-Infrared Spectrometer for Agriculture and Food Processing

Contact Now

Rapid and Non-Destructive Testing JINSP SR100N25 Micro Near-Infrared Spectrometer for Agriculture and Food Processing

Minimum Order Quantity :	1	Price :	USD21900 - USD24300
Packaging Details :	International Shipping Package	Delivery Time :	30-50 working days
Payment Terms :	T/T,Western Union	Supply Ability :	200PCS 40-60 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	ISO9001	Model Number:	SR100N25

Detail Information
Type:	Refrigerated Linear Array InGaAs	Effective Pixel:	512
Sensing Area:	12.8mm*0.5mm	Wavelength Range:	900~2500nm
Optical Design:	F/4 Cross-type	Optical Resolution:	6.3nm(@25μm)

Product Description

SR100N25 Cooled Near-Infrared Spectrometer

Integrate the JINSP SR100N25 as a robust NIR sensor for online industrial process control. Monitor moisture, composition, and quality in real-time for pharmaceuticals, food, and chemicals.

Integrate real-time analytical power into your production line with the JINSP SR100N25 industrial near-infrared spectrometer. Engineered for reliability and performance, this instrument is more than a lab tool—it's a robust sensor for continuous process monitoring and control (PAT) in demanding industrial environments.

Apply the SR100N25 to monitor moisture content in production streams, verify raw material composition (e.g., fat, protein, fiber), or identify product conformity. Its ability to perform non-destructive analysis makes it perfect for 100% online quality inspection, reducing waste and ensuring product consistency.

Technical Specifications:

	Performance Indicators	Parameters
Detector	Type	Refrigerated linear array InGaAs
	Eﬀective Pixel	512
	Pixel Size	25μm*500μm
	Sensing Area	12.8mm*0.5mm
Optical Parameters	Wavelength Range	900-2500nm
	Optical Resolution	6.3nm(@25μm)
	Optical Design	F/4 cross-type
	Numerical Aperture	0.14
	Focal Length	100mm
	Entrance Slit Width	5μm ,10μm ,25μm ,50μm (customizable)
	Incident Light Interface	SMA905 ﬁber interface, free space
Electrical Parameters	Integration Time	1ms-200ms
	Data Output Interface	USB2.0 ,UART
	ADC Bit Depth	16-bit
	Power Supply	DC4.9 to 5.1V(type @5V)
	Operating Current	＜3A
	Operating Temperature	10°C~40°C
	Storage Temperature	-20°C~60°C
	Operating Humidity	＜90%RH (no condensation)
Physical Parameters	Dimensions	178mm123mm49mm
Physical Parameters	Weight	1.2kg

Typical Applications:

Moisture content measurement and wastewater testing
Substance detection such as fat, oil, protein and fiber

Grain and fodder quality testing
Identification of illegal drugs components

Technical Characteristics:

512 pixels, cooled type, high resolution, low stray of light
Receive SMA905 fiber input to obtain free space optical
Compatible with USB or UART interface to output measured spectrum data
Lens surface is plated with gold film, high efficiency of near-infrared reflection

Company Introduction:

JINSP – Advanced Spectral Detection for Demanding Industries
Need high-accuracy Raman, FT-IR, or LIBS solutions? JINSP Company Limited brings 17 years of expertise, 200+ patents, and full ISO compliance to deliver certified detection systems. Based in Beijing with a Jiangsu production base, we support clients with CE, ECAC, IP Level, and transport safety certifications. From security checkpoints to lab analysis, JINSP’s technology is globally trusted.

FAQ

Q: This is the first time I use,is it easy to operate?

A: We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.Also our technicians will offer professional tecnical opearation meetings.

Q: Can your offer a operation traning?
A: Your technicians can come to our factory for a training. Jinsp engineers can go to your place for local support( installation , training, debugging, maintenance ).

Q: What's your website?
A: You can visit:www.jinsptech.com

Q: What about your quality assurance?

A: We have a quality inspection team. All goods will go through quality inspection before shipment. We can send you pictures for inspection.
