Tailored for Integration: OEM Customization Options for the ST830E OCT Spectrometer

Original Equipment Manufacturer (OEM) integration requires more than just a high-performance spectrometer—it demands flexibility, customization capability, and a partner who understands the challenges of system development. The JINSP ST830E OCT spectrometer series is designed from the ground up with OEM integration in mind, offering customizable wavelength ranges, camera options, and interface configurations to meet diverse application requirements.

The wavelength range of the ST830E is customizable within the 790-930nm range, allowing system integrators to optimize the spectrometer for specific light sources and imaging applications. For ophthalmic OCT systems operating at 840nm, the standard configuration provides optimal performance. For industrial inspection applications requiring different center wavelengths or spectral bandwidths, custom configurations are available. This flexibility ensures that the spectrometer's spectral response precisely matches the system's illumination source, maximizing SNR and imaging depth.

Camera options represent another dimension of customization. The ST830E supports multiple camera configurations, including E2V USB3.0, E2V Camera Link, and domestic CXP interface cameras. Each camera option offers different performance characteristics: USB3.0 provides cost-effective integration with scan rates up to 130kHz; Camera Link unlocks the full 250kHz capability; and the CXP (CoaXPress) interface offers an alternative high-speed solution. This camera flexibility allows OEMs to select the optimal detector for their specific speed, cost, and integration requirements.

The spectrometer's compact form factor—260×180×80mm for the ST830E and 200×100×60mm for the ST850E—facilitates integration into space-constrained systems. The 1.5kg weight reduces mounting requirements and simplifies system design. The FC/APC fiber optic input interface ensures consistent, reliable optical connections. These physical attributes make the ST830E suitable for integration into benchtop systems, portable devices, and production-line inspection stations.

OEM integration is further simplified by the mature, stable design that requires no frequent recalibration. This reliability is essential for OEMs deploying systems in the field, where maintenance access may be limited. The robust construction and wide operating temperature range (0°C to 50°C) ensure consistent performance across diverse deployment environments.

JINSP's 17+ years of experience in spectral detection technology provides OEM customers with confidence in both product quality and technical support. The company's supply capability—100 units per 40-60 working days—ensures that production-scale requirements can be met. CE and ISO9001 certifications provide additional assurance for medical device manufacturers and quality-sensitive industrial applications.

For OEMs developing OCT-based products—whether ophthalmic diagnostic systems, industrial inspection tools, or research instruments—the ST830E's customization options and integration-friendly design provide a solid foundation for successful product development. The ability to tailor wavelength ranges, camera configurations, and interface options ensures that the spectrometer can be optimized for the specific requirements of each application.

Technical Parameters:

Company Introduction:

JINSP Company Limited has won the National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate and the China Patent Excellence Award, and related products have been obtained has won authoritative awards such as the Geneva International Invention Award, the Beijing New Technology and New Product Certificate, and the "Innovation Achievement Award" of the Zhu Liangyi Analytical Instrument Innovation Award.JINSP is a professional leading solution provider of molecular spectroscopy, particulaly in Roman Spectroscopy for many years.

Our products mostly include:
--OCT spectrometers;
--Desktop/portable, online Raman analyzers for laboratory or indutrial liquid & gas analysis;
--On-site rapid detectors/identifiers based on Raman technology for drugs, liquid, food safety, explosive & hazardous materials, pharmaceutical industry etc;

FAQ:

Q1: What is the brand name of this OCT Spectrometer?

A1: The brand name of this OCT Spectrometer is JINSP.

Q2: What is the model number of this OCT Spectrometer?

A2: The model number of this OCT Spectrometer is ST830E.

Q3: Where is this OCT Spectrometer made?

A3: This OCT Spectrometer is made in China.

Q4: What are the payment terms for this OCT Spectrometer?

A4: The payment terms for this OCT Spectrometer are T/T and Western Union.
