Precision Industrial Inspection: ST850E OCT Spectrometer for Nondestructive Testing and Quality Control

The transition of optical coherence tomography from medical laboratories to industrial floors has created new opportunities for non-contact, high-resolution inspection of manufactured components. JINSP ST850E OCT spectrometer is engineered to meet the rigorous demands of industrial nondestructive testing (NDT), delivering the imaging depth, speed, and reliability required for quality control in welding, coating, and advanced manufacturing applications.

ST850E variant offers an exceptional 7mm imaging depth, making it ideally suited for industrial applications where thicker samples must be inspected. With a wavelength range of 824-876nm and optical resolution of 0.025nm, the spectrometer provides the fine spectral resolution necessary to detect microscopic defects in metal surfaces, weld pools, and multilayer coatings. The Camera Link interface delivers the full 250kHz line scan rate, enabling real-time inspection of moving production lines.

Key industrial applications include laser welding inspection, where the ST850E enables real-time monitoring of weld penetration depth and morphology. During laser welding processes, the spectrometer captures cross-sectional images of the weld pool, allowing operators to detect defects such as incomplete fusion, porosity, and underfill in real time. The high scan rate ensures that fast-moving welds are captured with sufficient temporal resolution, while the deep imaging depth provides visibility into the full weld structure.

In metal cutting and machining applications, the ST850E supports high-precision depth measurement of drilled holes and machined features. The spectrometer's excellent roll-off performance ensures that signal quality is maintained even at significant depths, enabling accurate measurement of deep features that would challenge conventional inspection methods. This capability is particularly valuable in aerospace and automotive manufacturing, where component quality directly impacts safety and performance.

The ST850E also excels in coating and surface inspection applications. Multilayer coatings—used in optics, electronics, and protective finishes—require precise thickness measurement and uniformity assessment. The spectrometer's high spectral resolution enables differentiation of individual coating layers, while the imaging depth allows visualization of the complete coating stack. For electronic display manufacturing, the ST850E supports flatness and uniformity inspection of glass panels and thin-film layers.

The spectrometer's robust design is optimized for industrial environments. With an operating temperature range of 0°C to 50°C and humidity tolerance below 85% RH (non-condensing), the ST850E maintains stable performance in factory conditions. The mature, stable design requires no frequent recalibration—a critical advantage in production environments where downtime is costly. The FC/APC fiber optic interface ensures reliable optical connections even in vibration-prone industrial settings.

JINSP's 17+ years of experience in spectral detection technology ensures that the ST850E delivers the reliability and consistency that industrial users demand. With customizable wavelength ranges and camera options, the spectrometer can be tailored to specific inspection requirements. For manufacturers seeking to implement OCT-based quality control, the ST850E provides a proven, production-ready solution.

Technical Parameters:

Company Introduction:

JINSP Company Limited has won the National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate and the China Patent Excellence Award, and related products have been obtained has won authoritative awards such as the Geneva International Invention Award, the Beijing New Technology and New Product Certificate, and the "Innovation Achievement Award" of the Zhu Liangyi Analytical Instrument Innovation Award.JINSP is a professional leading solution provider of molecular spectroscopy, particulaly in Roman Spectroscopy for many years.

Our products mostly include:
--OCT spectrometers;
--Desktop/portable, online Raman analyzers for laboratory or indutrial liquid & gas analysis;
--On-site rapid detectors/identifiers based on Raman technology for drugs, liquid, food safety, explosive & hazardous materials, pharmaceutical industry etc;

FAQ:

Q1: What is the brand name of this OCT Spectrometer?

A1: The brand name of this OCT Spectrometer is JINSP.

Q2: What is the model number of this OCT Spectrometer?

A2: The model number of this OCT Spectrometer is ST830E.

Q3: Where is this OCT Spectrometer made?

A3: This OCT Spectrometer is made in China.

Q4: What are the payment terms for this OCT Spectrometer?

A4: The payment terms for this OCT Spectrometer are T/T and Western Union.
