JINSP SR75C Compact Spectrometer with High Resolution and Signal-to-Noise Ratio for Accurate Absorption and Transmission Studies

Contact Now

JINSP SR75C Compact Spectrometer with High Resolution and Signal-to-Noise Ratio for Accurate Absorption and Transmission Studies

Minimum Order Quantity :	1	Price :	USD1200- USD1300
Packaging Details :	Customized Packaging	Delivery Time :	30-50 working days
Payment Terms :	T/T,Western Union	Supply Ability :	100 PCS/70-90 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE	Model Number:	SR75C

Detail Information
Wavelength Range:	200nm-1100nm	Detector Type:	Linear Array CMOS, Hamamatsu S11639
Optical Design:	Type M C-T Light Path	Grating Slits:	10μm, 25μm, 50μm, 100μm, 200μm (customizable)
Weight:	310g	Dimension:	110mm95mm43mm
Interface:	USB 2.0	Optical Interface:	FC/PC Or SMA905
Highlight:	compact spectrometer high resolution , compact spectrometer signal-to-noise ratio , compact spectrometer absorption transmission studies

Product Description

Miniature Fiber Optic Modular Spectrometer JINSP SR75C

Optimize your spectral analysis with the JINSP SR75C—a versatile and high-resolution spectrometer. It features a 2048-pixel array, wide wavelength range, and superior optical design for minimal aberration. The built-in temperature compensation ensures consistent performance under varying operational conditions.

From flue gas analysis to water quality testing, the SR75C offers reliable results for challenging environments. Its dual output interfaces support seamless connectivity, providing a practical and efficient solution for continuous monitoring and data acquisition.

Product Parameters:

	Performance Indicators	Parameters
Detector	Chip Type	Linear array CMOS, Hamamatsu S11639
	Eﬀective Pixel	2048
	Pixel Size	14μm *200μm
	Sensing Area	28.7mm *0.2mm
Optical Parameters	Optical Design	M Type C-T light path
	Numerical Aperture	0.085
	Entrance Slit Width	10μm, 25μm, 50μm, 100μm, 200μm (customizable)
	Spectrum Range and Resolution	See model table for details
	Fiber Input Interface	SMA905, free space
Electrical Parameters	Integration Time	1ms-60s
	Signal-to-Noise Ratio	650:1 (4ms)
	Data Output Interface	USB 2.0 or serial port
	ADC Bit Depth	16-bit
	Power Supply	DC 4.5V to 5.5V (type @5V)
	Operating Current	< 500mA
Others	Operating Temperature	10°C ~ 40°C
	Storage Temperature	-20°C ~ 60°C
	Operating Humidity	＜90%RH (no condensation)
	Dimensions	110mm95mm40.5mm
	Weight	310g

Model	Spectral Range (nm)	Resolution (nm)	Slit (μm)
SR75C-G02	510~1000 (VIS-NIR)	0.8	25
SR75C-G02	510~1000 (VIS-NIR)	0.5	10
SR75C-G04 SR75C-G06 SR75C-G07 SR75C-G08 SR75C-G09 SR75C-G10	200~450(UV) 330~570(VIS) 550~750(VIS) 750-900(NR)	0.3-0.5	25
	200~450(UV) 330~570(VIS) 550~750(VIS) 750-900(NR)	0.2-0.3	10
	180~340( UV) 500~600(VIS)	0.3	25
	180~340( UV) 500~600(VIS)	0.15~0.2	10

* Customization available for other ranges

Typical Applications:

Absorption, transmittance, and reflectance detection In ultraviolet, visible, and near-infrared range;
Detection of light source and laser wavelength;
OEM product module:

LIBS – analysis of soil and minerals for geological testing and mining-related work

Online monitoring of water quality and environmental protection - organic matter and oxygen content in water

Flue gas - Monitoring and identification of flue gas emission components

Technical Characteristics:

Wide Spectral Range Supports customized spectrum range of 200-1000nm
High Signal-to-Noise Ratio Low-noise CMOS signal processing circuit, with excellent signal-to-noise ratio
High Resolution M-shape C-T optical design

JINSP SR75C Compact Spectrometer with High Resolution and Signal-to-Noise Ratio for Accurate Absorption and Transmission Studies 0

Company Introduction:

Innovation-Centric JINSP – Pioneering Spectral Detection Since 2007
For over 17 years, JINSP Company Limited has been a technology leader in Raman, FT-IR, and LIBS spectral analysis. Our 200+ patented innovations reflect our dedication to world-class R&D. Operating from Beijing with a Jiangsu production plant, we combine precision engineering with ISO and international certifications (CE, ECAC, ICT, etc.). Whether for security, environmental, or industrial use, JINSP’s cutting-edge spectral solutions set the benchmark for accuracy and reliability.

FAQ:

Q1: Is the price of this product negotiable?

A1: Yes, the price of this product is negotiable.

Q2: What are the payment terms for this product?

A2: The payment terms for this product are T/T and Western Union.

Q3: What is the supply ability for this product?

A3: The supply ability for this product is 100 PCS/70-90 days.

Q4: How long does it take to deliver this product?

A4: The delivery time for this product is 30-50 working days.
