Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device

Contact Now

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device

Minimum Order Quantity :	1	Price :	USD100000 - USD142900
Packaging Details :	International Shipping Package	Delivery Time :	90-120 working days
Payment Terms :	T/T, Western Union	Supply Ability :	50 Unit 90-120 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE ISO9001	Model Number:	RS2600

Detail Information
Model Name:	RS2600 Multi-gas Analyzer	Laser Excitation Wavelength:	532 ± 0.5 Nm
Spectral Coverage:	200 ~ 4200 Cm-1	Analysis Time:	2 Seconds
Detection Limit:	Ppm Level	Measurement Time:	Real-time
Highlight:	Multi Gas Raman Gas Spectroscopy Analyzer , Multi Gas Raman Gas Analyse Device , Eco Friendly Raman Gas Spectroscopy Analyzer

Product Description

Raman Spectroscopy Multi-gas Analyzer for Simultaneous Online Analysis

Meet stringent emissions standards with RS2600's real-time multi-pollutant tracking. Capable of concurrent analysis of CO₂, CH₄, and fluorinated gases (PF5), this system simplifies stack testing with laboratory-grade accuracy in field conditions. Its non-depletion sampling preserves evidence for audit trails.

The wide dynamic range (ppm-100%) handles both fugitive emissions and process streams, while isotopic discrimination (H2 vs D2) aids in greenhouse gas source identification. Regulatory bodies increasingly recognize its NIST-traceable data for compliance reporting across petrochemical and metallurgical sectors.

Technical Specifications:

Components	N2, H2, O2, CO, CO2, H2S, CmHn, etc.
Analysis time	2 seconds
Measurement uncertainty	≤0.2%
Laser excitation wavelength	532 ± 0.5 nm
Spectral coverage	200 ~ 4200 cm-1
Spectral resolution	≤8 cm-1 at full spectral range
Air circuit interface	6 mm standard tube fitting (3 mm, 1/8’’, and 1/4’’ are optional)
Input voltage	100~240 VAC,50~60 Hz
Sample gas temperature	-50 ~ 40 ºC
Sample gas pressure	＜1.0 MPa
Unit dimensions	485 mm (Width) × 350 mm (Height) × 600 mm (Depth)
Weight	40 kg

Technical highlights:

Non-destructive gas analysis: Analytes including homonuclear diatomic gases(F2, Cl2, etc.) and isotopic gases (H2, D2, T2, etc.)
Short detection time: Data acquired in seconds
Minimal maintenance: Resistance to high pressure, direct detection without consumables (chromatographic column or carrier gas)
Wide detection range: LOD at ppm level, detection range up to 100%

Main Applications:

Application: 1. Monitoring of F2, N2, HF and other components in the fluorination process.

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 0

Application: 2. Quantitative analysis of different Elements in Petrochemical Natural Gas

Effective identification and quantification of various components in natural gas mixtures within 2 seconds, such as alkanes, alkenes, alkynes, etc.

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 1

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 2

Application: 3. Detection of components in reaction and emitted gases of fluorine materials, such as reactant gases, common gases, fluoinated gases.

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 3

Application: 4. Detection of impurity gases and electronic special gases.

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 4

Gas Analyzer Features:

By constructing quantitative models of multiple standard curves and combining them with chemometric methods, the correlation between spectral signals and the content of various component substances can be effectively established. This comprehensive method not only improves the accuracy of analysis, but also enables the simultaneous processing and analysis of multiple different chemical components, providing a powerful tool for quantitative analysis of complex samples.
Even in the case of changes in sample gas pressure or fluctuations in testing conditions, this quantitative analysis method can still maintain the accuracy of the results. This is due to its high stability and robustness, ensuring consistent analysis results in any environment, providing reliable data support for scientific research and industrial applications.

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 5

Company Introduction:

JINSP Company Limited, abbreviated as "JINSP", is a professional supplier with over 17 years of experience in spectral detection technology products, including Raman, FT-IR, LIBS technologies, etc. After 17 years of technology accumulation, the company’s core key technologies have reached the international leading position at the level, and the cumulative number of patent applications exceeded 200.

JINSP offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security, and customs. Products are available nationwide and are exported to over 30 countries, with cumulative sales exceeding 3,000 units.

Benefit from 30+ R&D engineers, including 4 Ph.D., JINSP is deeply rooted in the field of personalized product customization, and is committed to meeting the diverse and unique needs of customers with excellent professional technology and innovative design capabilities.

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 6

Multi Gas Eco Friendly Raman Gas Spectroscopy Analyzer Raman Gas Analyse Device 7

FAQ:

Q:This is the first time I use,is it easy to operate?

A:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.Also our technicians will offer professional tecnical opearation meetings.

Q2:Can you offer a operation training?
A:Your technicians can come to our factory for a training. Jinsp technical engineers can go to your place for local support.
( installation, training,debugging,maintenance )

Q3:How to receive a best price in the shortest time?

A:When you send us an inquiry,please kindly offer details with wavelength,detector,effective pixels,focal length and so on.We will send you quotation with details soon to your email.

Q: Do you have MOQ requirement of each order?

A: No, we support order for even 1pc order.

Q: What is the product warranty?

A: All product has 1 year warranty, support extending warranty period with extra cost. Please contact with our sales person.
