Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser

Contact Now

Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser

Minimum Order Quantity :	1PC	Price :	USD25800 - USD28600
Packaging Details :	1PC/BOX	Delivery Time :	30 working days
Payment Terms :	T/T	Supply Ability :	20 PCS PER MONTH

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE ISO9001	Model Number:	LB1000S

Detail Information
Spectral Range:	180nm ~ 460nm	Laser Wavelength:	1535nm
Laser Safety:	Class1, The Lowest Risk Among All The Laser Classes	Brand Library:	400+, Can Be Added Or Edited
Communication Mode:	4G,Bluetooth,WIFI	Working Temperature:	-10℃ ~ +40℃
Memory:	16GB	Continuous Working Time:	8 Hours
Highlight:	Lightweight Libs Metal Analyzer , Lightweight Spectroscopy LIBS Analyser , CE Certified Libs Metal Analyzer

Product Description

Handheld LIBS for detection of alloys low content aluminum Si and the elements before Mg

The use of 1535nm CLASS 1 eye-safe lasers makes this LIBS Elemental Analyzer safe and worry-free. It eliminates the hidden dangers of X-ray ionizing radiation, making it a safe choice for metal detection applications.

With an approximate weight of 1.9kg, this Handheld Element Analyzer is easy to carry around, making it a Portable LIBS Analyzer. Its compact size and lightweight design make it an ideal choice for on-site inspections, providing accurate and reliable results without the need for a laboratory setting.

Technical Highlights:

Safe and worry-free: Using 1535nm CLASS 1 eye-safe lasers completely eliminates the hidden dangers of X-ray ionizing radiation. The externally limited device is carefully designed to effectively prevent laser misfiring, ensuring the safety of every user.
Efficient and prompt: Whether it's thin sheets, large blocks, lines, or particles, we can quickly respond to various shapes of metals. Detection results can be issued within 5 seconds on site, making your workflow smoother and without any waiting.
Intelligent recognition: Automatically identify the type of metal matrix to avoid human error and make the detection results more accurate. Additionally, the device integrates Beidou positioning, 4G/5G, and WIFI networking capabilities, allowing you to upload detection data to the business system in real time regardless of your location.
Accurate and reliable: With full-element detection capabilities, it also demonstrates excellent detection results for light elements such as Al, Mg, and Si. This meets the precise analysis requirements of various industries, providing strong support for your business.
Wide compatibility: Capable of detecting aluminum-based, copper-based, and iron-based matrices, it can perform quantitative analysis of various alloy elements such as Cr, Ni, Ti, V, Mn, Mg, etc. We also provide matrix customization services to meet your specific needs.

Specifications:

Detection Alloy Matrix	Aluminum based elements: Al,Si,Fe,Cu,Zn,Mg,Mn,Ni,Cr,Ti,Pb,Sn Iron based elements: Fe,Cr,Ni,Mn,si,Ti,Cr,Mo,V,Co Copper based elements: Cu,Zn,Mn,Al,Ni,Pb,Sn,Fe
Spectral range	180nm ~ 460nm
Laser wavelength	1535 nm, much safer for human eyes
Laser safety	Class1, the lowest risk among all the laser classes
Display screen	5.0-inch capacitive touch screen
Memory	16Gb
Working environment	Temperature: -5 to 40℃. Humidity: ≤95%RH, no condensation
Sample types	Bulk solids, cylinders, sheets, wires with a diameter of 1mm or larger, thin slices, large blocks, lines, particles
Communication mode	4G,Bluetooth,WIFI
Operating time	8 hours

1	Aluminum based
Main Element	LOD (ppm)	LOD %(Min)	LOD %(Max)
Fe	＜2000	0	1
Si	500	0	8
Zr	2000	0	8
Pb	2000	0	1
Cu	＜500	0	10
Zn	＜1000	0	2
Mn	1000	0	0.1
Ni	＜500	0	0.1
Ti	＜500	0	0.1
Mg	＜500	0	18
Sr	＜500	0	0.1
Sn	1000	0	0.1
Cr	＜500	0	0.1
Sc	＜500	0	0.1
Be	＜20	0	0.01
Ag	＜500	0	0.5
Al		Balance	Balance

2	Copper based
Main Element	LOD (ppm)	LOD %(Min)	LOD %(Max)
Al	＜800	0	8
Si	1500	0	0.5
Pb	500	0	5
Zn	＜800	0	40
Mn	＜500	0	13
Ni	2000	0	28
Fe	1000	0	5
Sn	2000	0	0.5
Co	1500	0	2
Nb	300	0	0.5
Cr	＜800	0	1
Cu		Balance	Balance

3	Iron based
Main Element	LOD (ppm)	LOD %(Min)	LOD %(Max)
V	1000	0	2
Al	＜1000	0	1
Si	＜5000	0	3
Cu	3000	0	3
Co	1500	0	13
Mn	＜1000	0	22
Ni	5000	0	40
Ti	＜1000	0	1
Mo	1000	0	6
Cr	5000	0	22
Fe		Balance	Balance

Applications:

The LIBS Elemental Analyzer is efficient and prompt as detection results can be issued within 5 seconds on site, making your workflow smoother and without any waiting. It weighs approximately 1.9kg with battery and has a continuous working time of 8 hours. It is an accurate and reliable product with full-element detection capabilities, including excellent detection results for light elements such as Al, Mg, and Si.

Recycled metal recovery
Utilization of recycled metals
Scrap metal and alloys

Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser 0

Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser 2

Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser 3

Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser 4

Support and Services:

The Handheld Element Analyzer is a powerful tool for identifying and analyzing elements in various materials. Our product technical support team is available to assist with any questions or issues that may arise during the use of the analyzer. We provide a range of services to ensure that your analyzer is functioning properly and delivering accurate results. These services include:

Installation and setup support
Calibration and maintenance services
Training and education on proper use and handling of the analyzer
Repair and replacement services
Software and firmware updates

Our technical support team is dedicated to providing timely and effective solutions to any issues you may encounter with your handheld element analyzer. We are committed to ensuring that you get the most out of your investment and are satisfied with your purchase.

Company Introduction:

JINSP Company Limited, abbreviated as "JINSP", is a professional supplier with over 17 years of experience in spectral detection technology products, including Raman, FT-IR, LIBS technologies, etc. After 17 years of technology accumulation, the company’s core key technologies have reached the international leading position at the level, and the cumulative number of patent applications exceeded 200.

JINSP offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security, and customs. Products are available nationwide and are exported to over 30 countries, with cumulative sales exceeding 3,000 units.

Benefit from 30+ R&D engineers, including 4 Ph.D., JINSP is deeply rooted in the field of personalized product customization, and is committed to meeting the diverse and unique needs of customers with excellent professional technology and innovative design capabilities.

Lightweight Libs Metal Analyzer CE Certified Spectroscopy LIBS Analyser 5

FAQ:

1. What is the model number of this handheld element analyzer?
Model Number: LB1000S.

2. Where is this handheld element analyzer manufactured?
Place of Origin: CHINA.

3. What is the minimum order quantity for this handheld element analyzer?
Minimum Order Quantity: 1PC.

4. What are the payment terms for purchasing this handheld element analyzer?
Payment Terms: T/T.

5. What is the supply ability of this handheld element analyzer?
Supply Ability: 20 PCS PER MONTH.
