Specifications:
|
Detection Alloy Matrix
|
Aluminum based elements: Al,Si,Fe,Cu,Zn,Mg,Mn,Ni,Cr,Ti,Pb,Sn
Iron based elements: Fe,Cr,Ni,Mn,si,Ti,Cr,Mo,V,Co
Copper based elements: Cu,Zn,Mn,Al,Ni,Pb,Sn,Fe
|
|
Spectral range
|
180nm ~ 460nm
|
|
Laser wavelength
|
1535 nm, much safer for human eyes
|
|
Laser safety
|
Class1, the lowest risk among all the laser classes
|
|
Display screen
|
5.0-inch capacitive touch screen
|
|
Memory
|
16Gb
|
|
Working environment
|
Temperature: -5 to 40℃.
Humidity: ≤95%RH, no condensation
|
|
Sample types
|
Bulk solids, cylinders, sheets, wires with a diameter of 1mm or larger, thin slices,
large blocks, lines, particles
|
|
Communication mode
|
4G,Bluetooth,WIFI
|
|
Operating time
|
8 hours
|
Technical Highlights:
- Safe and worry-free: Using 1535nm CLASS 1 eye-safe lasers completely eliminates the hidden dangers of X-ray ionizing radiation. The externally limited device is carefully designed to effectively prevent laser misfiring, ensuring the safety of every user.
- Efficient and prompt: Whether it's thin sheets, large blocks, lines, or particles, we can quickly respond to various shapes of metals. Detection results can be issued within 5 seconds on site, making your workflow smoother and without any waiting.
- Intelligent recognition: Automatically identify the type of metal matrix to avoid human error and make the detection results more accurate. Additionally, the device integrates Beidou positioning, 4G/5G, and WIFI networking capabilities, allowing you to upload detection data to the business system in real time regardless of your location.
- Accurate and reliable: With full-element detection capabilities, it also demonstrates excellent detection results for light elements such as Al, Mg, and Si. This meets the precise analysis requirements of various industries, providing strong support for your business.
- Wide compatibility: Capable of detecting aluminum-based, copper-based, and iron-based matrices, it can perform quantitative analysis of various alloy elements such as Cr, Ni, Ti, V, Mn, Mg, etc. We also provide matrix customization services to meet your specific needs.
Applications:
- Recycled metal recovery
- Utilization of recycled metals
- Mineral exploration
Company Introduction:
JINSP Company Limited, abbreviated as "JINSP", is a professional supplier with over 17 years of experience in spectral detection technology products, including Raman, FT-IR, LIBS technologies, etc. After 17 years of technology accumulation, the company’s core key technologies have reached the international leading position at the level, and the cumulative number of patent applications exceeded 200.
JINSP Company received ISO9001:2015, ISO14001:2015, and ISO45001:2018 certifications. JINSP can provide required certifications, such as certification by the Ministry of Public Security or National Institute of Metrology, Environmental Level Certification, IP Level Certification, CE Certification, Transport Identification Report, EU ECAC certification, German ICT Security Testing, etc.
The technology owned by JINSP has won the National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate and the China Patent Excellence Award, and related products have been obtained has won authoritative awards such as the Geneva International Invention Award, the Beijing New Technology and New Product Certificate, and the "Innovation Achievement Award" of the Zhu Liangyi Analytical Instrument Innovation Award. In addition, JINSP participated in the drafting of several national and international standards, including participating in the drafting of an international standard as the only participating unit in China IEC 63085 International Standard: System of spectral identification of liquids in transparent or semitransparent containers; Drafting of two national standards: GB/T 41086-2021 "General Technical Requirements for Safety Inspection Equipment for Hazardous Chemicals Based on Raman Spectroscopy", GB/T 40219-2021 "General Specification for Raman Spectrometer".
FAQ:
Q1: What is the brand name of this handheld element analyzer?
A1: The brand name of this handheld element analyzer is JINSP.
Q2: What is the model number of this handheld element analyzer?
A2: The model number of this handheld element analyzer is LB1000S.
Q3: What is the place of origin of this handheld element analyzer?
A3: The place of origin of this handheld element analyzer is CHINA.
Q4: What is the minimum order quantity for this handheld element analyzer?
A4: The minimum order quantity for this handheld element analyzer is 1PC.
Q5: What are the payment terms for this handheld element analyzer?
A5: The payment terms for this handheld element analyzer are T/T.
